Freezers, Chest Freezer, Ultra-low Temperature, General Purpose, Thermo Scientific™

TDE Series -86°C Ultra-Low Temperature Chest Freezers, General Purpose
Thermo Scientific TDE Series ultra-low temperature chest freezers, part of the Standard Performance (STP) family of freezers powered by H-drive, feature three sizes, maximizing storage capacity from 3,645 up to 21,600 2mL vials. The workhorse of the busy lab, The TDE Series sets the standard for performance and reliable sample storage in heave use situations. A sustainable solution with ultimate sample security and operational savings for every lab.

User Friendly
  • The H-drive Information Center (HIC) combines easy to read temperature with simple capacitive touch buttons in a 5.6 inch display
  • Three sizes (3, 13, and 20 cu.ft.) to accommodate a variety of storage needs and lab footprint specifications
  • Improved customer convenience with new ergonomically designed handle, high contrast easy-to-read display, and convenient additional workspace.
  • Compatible with most racking systems including a full range of Thermo Scientific racks for boxes, microplates, Thermo Scientific Matrix™ and Nunc CryoBank™ tubes
  • Security features including alarm settings and key-lock door
Sustainability
  • Lower HVAC costs as a result of less heat emission into the environment
  • Natural refrigerants and Polyurethane foam with non-HFC blowing agent having zero GWP, making the Series compliant with the U.S. Environmental Protection Agency’s Significant New Alternatives Policy (SNAP), the European Union’s F-Gas and other sustainability standards
GSA

Performance
  • Powered by H-drive's hydrocarbon technology, these systems save up to 25% in energy usage and heat rejection over conventional refrigerant ultra-low freezers
  • Designed for daily usage, recovers cabinet temperature 20% faster after opening the door
  • A quiet sound output below 55 dBA, enables the freezer to come out of the hallway and into the lab
  • Meets +/-10°C validation protocols at -80°C with strong peak variation and steady-state temperature variation
  • Natural hydrocarbon refrigerants reduce system operating stresses promoting outstanding reliability and worry-free sample protection
  R212-1 R212-11 R212-12 R212-21 R212-22
Capacity 3 cu.ft. (85L) 13 cu.ft. (360L) 20 cu.ft. (566L)
Temperature Range -50°C to -86°C
Door Style 1 Horizontal Solid
Cabinet Material Cold Rolled Steel
Interior Stainless Steel
Exterior Finish Painted Steel
Shelves None
Holds 63 Standard 2" boxes 252 Standard 2 inch boxes 396 Standard 2 inch boxes
Certifications/Compliance UL, cUL, RoHS, REACH, EPA SNAP, ISO 13485, Prop 65
Display HIC Touch Button
Casters 4 6
Condenser Type Air Cooled
Control Type Capacitive Touch UI
For Use With Optional LN2 Backup, CO2 Backup, Chart Recorder
Ports One Port Hole
Warranty 5 years
Defrost Manual
Lid Single Hand Lift
Water Cooled No
Exterior (DxWxH) 32.7 x 28.8 x 43.7"
(831 x 732 x 110mm)
33.1 x 72.3 x 40.5 inch
(841 x 1836 x 1029mm)
33.1 x 96.3x 40.5 inch
(841 x 2446 x 1029mm)
Interior (DxWxH) 18.4 x 18.4 x 16.4"
(467 x 467 x 417mm)
18.5 x 42.4 x 27.8 inch
(470 x 1077 x 706mm)
18.5 x 66.4 x 27.8 inch
(470 x 1687 x 706mm)
Monitoring Options Alarm, Recorder
Access Security Key Lock
Chart Recorder Optional
Data Outputs RS485, 4-20Ma, Dry Contacts, USB
Setpoint Security Single ID
Backup Systems CO2 or LN2 Optional
Connectivity Optional (Device Link Connect)
Smart View Compatibility Smart View Compatible
Plug Type NEMA 5-20P
Power 115V / 10.7A 115V / 11.2A 208/230V / 5.4A 115V / 13.6A 208/230V / 5.8A
Phase Single
Energy Usage 6.6 kW-hr/day 9.4 kW-hr/day 10.5-11.0 kW-hr/day
Green Features EcoFoam, Natural Hydrocarbon Refrigerants
Compressor H-Drive Compressor
Refrigerant R290/R170+R290 Mix
GSA Link

Ordering Info

Cat No Vendor Part No CapacityDoor StyleHoldsPower Qty Price Qty UOM
R212-1 TDEC06386FA 3cu.ft. (85L)Horizontal SolidStandard 2 inch boxes (63)115V In Stock 1 $14,700.00 EA
R212-11 TDEC25286FA 13cu.ft. (360L)Horizontal SolidStandard 2 inch boxes (252)115V In Stock 1 $18,300.00 EA
R212-12 TDEC25286FD 13cu.ft. (360L)Horizontal SolidStandard 2 inch boxes (252)208/230V In Stock 1 $18,300.00 EA
R212-21 TDEC39686FA 20cu.ft. (566L)Horizontal SolidStandard 2 inch boxes (396)115V In Stock 1 $23,000.00 EA
R212-22 TDEC39686FD 20cu.ft. (566L)Horizontal SolidStandard 2 inch boxes (396)208/230V In Stock 1 $23,000.00 EA
R212-25 TDEC39686FV 20cu.ft. (566L)Horizontal SolidStandard 2 inch boxes (396)230V In Stock 1 $23,000.00 EA
