Microscopes, Stereo Microscope, Trinocular, NexiusZoom Series
NexiusZoom Stereo Microscopes
NexiusZoom EVO- Precision and Versatility in Stereo Microscopy. Experience the epitome of high-precision examination and three-dimensional imaging with the NexiusZoom EVO stereo microscopes. Specifically engineered for your most demanding applications, these exceptional zoom microscopes provide unparalleled accuracy and clarity. Whether analyzing material surfaces or observing and preparing biological samples, the NexiusZoom EVO is your gateway to comprehensive insights.
- WF 10x/18mm eyepiece(s)
- Binocular and trinocular heads with HWF 10x/22mm or HWF 10x/23mm eyepieces (EVO) for comfortable and immersive viewing experiences
- Double 3W LED illumination, ensuring optimal illumination for your specimens
- Large working distance, allowing ample space for sample manipulation and preparation
- Zoom ratio of 1:8.4, offering a remarkable magnification range from 6.5x to 55x. Capture the finest details and explore the microscopic world with precision
- Ergonomic stands designed to provide optimal comfort during extended observation sessions
- Configurations available with magnification capabilities up to 220x, catering to a wide range of applications
- CE certified, guaranteeing compliance with rigorous international standards for safety and quality
- Backed by a 10-year warranty, providing peace of mind and long-term support for your investment
| |
M201-20 and M201-21 |
M201-22 and M201-23 |
M201-24 and M201-25 |
| Stand |
Rack and pinion, WD:110mm |
Pillar, WD:110mm |
| Illumination |
3W LED incident and transmitted simultaneously |
3W LED incident by two gooseneck arms and transmitted simultaneously |
| Head |
Trinocular 45º incline, 54-75mm interpupillary, ±5mm diopter adjustment on both eyepiece tubes |
| Eyepiece |
HWF10x/23mm |
| Focusing |
Macro on both sides of the head holder |
| Objective |
0.65x-5.5x zoom (6.5x – 55x) |
| Stage |
Plain with clips, black/White and clear plates |
Ordering Info
| Cat No |
Description | Head | Eyepiece | Illumination | Stand |
Qty |
Price |
Qty |
UOM |
| M201-20 |
Trinocular Microscope | 45º incline, 54-75mm interpupillary, ±5mm diopter adjustment on both eyepiece tubes | HWF10x/23mm | 3W LED incident and transmitted simultaneously | Rack and pinion, WD:110mm |
In Stock |
1 |
$1,549.00 |
|
EA |
| M201-21 |
Trinocular Microscope w/Camera | 45º incline, 54-75mm interpupillary, ±5mm diopter adjustment on both eyepiece tubes | HWF10x/23mm | 3W LED incident and transmitted simultaneously | Rack and pinion, WD:110mm |
In Stock |
1 |
$2,408.00 |
|
EA |
| M201-22 |
Trinocular Microscope | 45º incline, 54-75mm interpupillary, ±5mm diopter adjustment on both eyepiece tubes | HWF10x/23mm | 3W LED incident and transmitted simultaneously | Pillar, WD:110mm |
In Stock |
1 |
$1,505.00 |
|
EA |
| M201-23 |
Trinocular Microscope w/Camera | 45º incline, 54-75mm interpupillary, ±5mm diopter adjustment on both eyepiece tubes | HWF10x/23mm | 3W LED incident and transmitted simultaneously | Pillar, WD:110mm |
In Stock |
1 |
$2,368.00 |
|
EA |
| M201-24 |
Trinocular Microscope | 45º incline, 54-75mm interpupillary, ±5mm diopter adjustment on both eyepiece tubes | HWF10x/23mm | 3W LED incident by two gooseneck arms and transmitted simultaneously | Pillar, WD:110mm |
In Stock |
1 |
$1,980.00 |
|
EA |
| M201-25 |
Trinocular Microscope w/Camera | 45º incline, 54-75mm interpupillary, ±5mm diopter adjustment on both eyepiece tubes | HWF10x/23mm | 3W LED incident by two gooseneck arms and transmitted simultaneously | Pillar, WD:110mm |
In Stock |
1 |
$2,796.00 |
|
EA |
