Ovens, Vacuum Oven, 16L - 264L

The Vacuum Ovens provide exceptional capabilities for fast and gentle drying of heat sensitive materials. They prevent residue accumulation on products also provide safe drying of flammable solvents. The units feature a radiant heating system that optimizes chamber space and provides excellent heat transfer and temperature uniformity. All vacuum ovens are built with stainless steel chambers that are easy to clean and have exceptional durability. The doors on these units have positive latch handles with spring-loaded glass to facilitate a good vacuum seal without hinge binds that shorten the gasket life. The tempered glass viewing window allows for safe, continuous monitoring of samples.

These Vacuum Ovens are some of the most rugged vacuum ovens available today. Each oven features overtemperature protection and an easy-to-read vacuum gauge. The Non-Economy Models (N138-9/9E, -10/10E, -11/11E, -12/12E) come with a fully programmable Watlow controller. The Vacuum Ovens are also equipped with silicone gaskets. While these gaskets resist a wide variety of temperatures and pressures, they can breakdown in the presence of solvents and acids. For solvent applications we recommend using Buna gaskets, and for acidic applications, the Fluorosilicone or Viton® gaskets.

• Moisture Determination
• Out Gassing Solids
• Aging Tests
• Plating
• Chemical Resistance Studies
• Drying of Paper
• Rubber and Textiles
• Desiccating
• Dry Sterilization
• Out Gassing Liquids
• Vacuum Storage
• Electronic Process Control
