Refrigerators, TSX Series, High-Performance Laboratory Refrigerator, Thermo Scientific
Thermo Scientific™ TSX Series high-performance lab refrigerators are designed with features that support sample protection and sustainability objectives for the storage of media, reagents, chemotherapy, pharmaceutical and other medical and laboratory-grade storage requiring 2° to 8°C. The Series’ V-drive technology is designed to provide temperature uniformity that continually adapts to user patterns, offering significant energy savings without compromising protection.
Click to view this Refrigerator as a 3D image
- Designed to safely store medical and laboratory storage, including vaccines, pharmaceuticals, media and reagents requiring a temperature range of 2°C to 8°C
- Whisper quiet with a sound level of 52 dBA, enabling end users to work alongside the refrigerator without distraction
- Unique V-drive technology is designed to detect usage patterns such as door openings when a higher compressor speed is needed and periods of stability where the compressor runs at a lower speed, saving energy without compromising protection
- Up to 40% less energy usage than conventional refrigerant models
- Natural, R290 refrigerants, making the TSX Series compliant with the U.S. Environmental Protection Agency’s Significant New Alternatives Policy (SNAP)
- Manufactured in an award-winning, zero-waste to landfill facility
- Operating temperature range of 2° to 8°C, factory setpoint at 5°C
- Choice of glass or solid door models
- Lower HVAC costs as a result of less heat emission into the environment
- Easy to use microprocessor control with interior light, setpoint security and alarms
- Compatible with wireless monitoring systems and remote alarm contacts
- Standard door locks provide comfort and assurance
- Ergonomic door handle
- Optional chart recorders available
- Warranty varies by country, please contact us for details
Industry Leading Parts and Labor Warranty: 5 years; Industry Leading Compressor Warranty: 10 years
(orders after July 1, 2023) |
| |
R203-150 |
R203-151 |
R203-154 |
R203-155 |
R203-152 |
R203-153 |
R203-156 |
R203-157 |
| Capacity |
11.5cu.ft. / 326L |
29.2cu.ft. / 827L |
| Chart Recorder |
Optional |
Exterior Dimensions
(L x W x H) |
30.5 x 24.0 x 73.0 inch
(77.5 x 61.9 x 185.4cm) |
31.1 x 24.0 x 73.0 inch
(79.0 x 61.9 x 185.4cm) |
37.3 x 34.0 x 78.5 inch
(94.7 x 86.4 x 199.4cm) |
37.8 x 34.0 x 78.5 inch
(96.0 x 86.4 x 199.4cm) |
Interior Dimensions
(D x W x H) |
21.8 x 20.0 x 52.4 inch
(55.4 x 50.8 x 133.1cm) |
28.5 x 30.0 x 58.0 inch
(72.3 x 76.2 x 147.3cm) |
| Door Style |
Glass |
Solid |
Glass |
Solid |
| Temperature Range |
2° to 8°C |
Electrical
Requirements |
115V, 60Hz, 15A |
208-230V, 50/60Hz, 15A |
115V, 60Hz, 15A |
208-230V, 50/60Hz, 15A |
115V, 60Hz, 15A |
208-230V, 50/60Hz, 15A |
115V, 60Hz, 15A |
208-230V, 50/60Hz, 15A |
| Weight |
285 lb / 129kg |
286 lb / 130kg |
390 lb / 177kg |
| Shelves |
4 |
| Plug Type |
NEMA5-15 |
NEMA6-15 |
NEMA5-15 |
NEMA6-15 |
NEMA5-15 |
NEMA6-15 |
NEMA5-15 |
NEMA6-15 |
| Certification,Compliance |
UL, cUL, Energy Star |
| Smart View Compatible |
Yes |
| Display |
Microprocessor |
| Refrigerant |
R290 |
| Defrost |
Automatic |
| |
R209-8 |
R209-9 |
R209-10 |
R209-11 |
R209-13 |
R209-19 |
R209-24 |
R209-25 |
| Capacity |
23cu.ft. / 650L |
23cu.ft. / 650L |
45.8cu.ft. / 1297L |
51.1cu.ft. / 1447L |
| Chart Recorder |
Optional |
Exterior Dimensions
(L x W x H) |
37 x 28 x 78.6 inch
(94 x 71.1 x 199.6cm) |
37 x 28 x 78.6 inch
(94x 71.1x 199.6cm) |
36.6 x 56.5 x 78.5 inch
(93.1x 143.5x 199.4cm) |
37.9 x 56.5 x 78.5 inch (96.2x 143.5x 199.4 cm) |
Interior Dimensions
(D x W x H) |
28.5 x 24 x 58 inch
(72.3 x 61 x 147.3 cm) |
28.5 x 24 x 58 inch
(72.3 x 61 x 147.3 cm) |
28.5 x 52.5 x 58 inch
(72.4x133.4x147.3cm) |
28.5 x 52.5 x 58 inch
(72.4x 133.4x 147.3 cm) |
| Door Style |
Glass |
Solid |
Sliding Glass |
Double Glass |
| Temperature Range |
3° to 7°C |
Electrical
Requirements |
115V, 60Hz, 15A |
208-230V, 50/60Hz, 15A |
115V, 60Hz, 15A |
208-230V, 50/60Hz, 15A |
115V, 60Hz, 1 Phase, 15A |
208-230V, 50/60Hz, 15A |
115V, 60Hz, 15A |
208-230V, 50/60Hz, 15A |
| Weight |
409 lb / 186kg |
388 lb / 176kg |
391 lb / 177kg |
370 lb / 168kg |
525 lb / 238kg |
525 lb / 238kg |
583 lb / 264kg |
583 lb / 264kg |
| Shelves |
4 |
8 Wire Shelves |
8 |
| Plug Type |
NEMA5-15 |
NEMA6-15 |
NEMA5-15 |
NEMA6-15 |
NEMA5-15 |
NEMA6-15 |
NEMA5-15 |
NEMA6-15 |
| Certification,Compliance |
UL, cUL, Energy Star |
UL, cUL |
| Smart View Compatible |
Yes |
| Display |
Microprocessor |
| Refrigerant |
R290 |
| Defrost |
Automatic |
Ordering Info
| Cat No |
Vendor Part No |
Capacity | Door Style | Plug Type | Power |
Qty |
Price |
Qty |
UOM |
| R203-150 |
TSX1205GA |
11.5 cu.ft. (326L) | Glass | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$9,110.00 |
|
EA |
| R203-151 |
TSX1205GD |
11.5 cu.ft. (326L) | Glass | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$9,320.00 |
|
EA |
| R203-154 |
TSX1205SA |
11.5 cu.ft. (326L) | Solid | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$8,520.00 |
|
EA |
| R203-155 |
TSX1205SD |
11.5 cu.ft. (326L) | Solid | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$8,710.00 |
|
EA |
| R209-8 |
TSX2305GA |
23 cu.ft. (650L) | Glass | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$10,100.00 |
|
EA |
| R209-9 |
TSX2305GD |
23 cu.ft. (650L) | Glass | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$10,300.00 |
|
EA |
| R209-10 |
TSX2305SA |
23 cu.ft. (650L) | Solid | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$9,290.00 |
|
EA |
| R209-11 |
TSX2305SD |
23 cu.ft. (650L) | Solid | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$9,290.00 |
|
EA |
| R203-152 |
TSX3005GA |
29.2 cu.ft. (827L) | Glass | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$11,000.00 |
|
EA |
| R203-153 |
TSX3005GD |
29.2 cu.ft. (827L) | Glass | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$11,300.00 |
|
EA |
| R203-156 |
TSX3005SA |
29.2 cu.ft. (827L) | Solid | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$10,200.00 |
|
EA |
| R203-157 |
TSX3005SD |
29.2 cu.ft. (827L) | Solid | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$10,400.00 |
|
EA |
| R209-13 |
TSX4505GA |
45.8 cu.ft. (1297L) | Sliding Glass | NEMA 5-15 | 115V / 60Hz / 8.6A |
In Stock |
1 |
$14,500.00 |
|
EA |
| R209-19 |
TSX4505GD |
45.8 cu.ft. (1297L) | Sliding Glass | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$14,500.00 |
|
EA |
| R209-24 |
TSX5005GA |
51.1 cu.ft. (1447L) | Double Glass | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$14,500.00 |
|
EA |
| R209-25 |
TSX5005GD |
51.1 cu.ft. (1447L) | Double Glass | NEMA 6-15 | 208-230V / 50/60Hz / 15A |
In Stock |
1 |
$14,500.00 |
|
EA |
| R209-35 |
TSX5005SA |
51.1 cu.ft. (1447L) | Double Solid | NEMA 5-15 | 115V / 60Hz / 15A |
In Stock |
1 |
$13,600.00 |
|
EA |
